ABB 266MST User Manual

18 OI/266/HART-EN Rev. M | 2600T Series Pressure transmitters
5 Mounting
142 (5.59)
(*)
70 (2.75)
179 (7.02)
91 (3.58)
166 (6.53)
70 (2.75)
84 (3.31)
117 (4.60)
29 (1.14)
18 (0.71)
18 (0.71)
11 (0.43)
210 (8.28)
58 (2.28)
55 (2.17)
95 (3.72)
174 (6.86)
Figure 15: Differential Pressure Style transmitter with barrel housing installed on a box pipe with optional bracket for SST housing (B5)
5.5.3 B5 Flat type bracket details
1 – U-bolt
2 – U-bolt fixing nuts and washers
3 – Transmitter fixing bolts
4 – B5 bracket
1
3
4
2
Figure 16: Flat type mounting bracket kit (B5)
