8 OI/266/HART-EN Rev. M | 2600T Series Pressure transmitters
3 Transmitter overview
3 Transmitter overview
3.1 Transmitter components overview
Figure 1: Differential pressure transmitter components
Figure 2: Gauge / absolute pressure transmitter components
2
Important. These two pictures show only two different kinds of transmitters equipped with Barrel type housing. Please consider that DIN
housings are available.
3
1
2
3
1 - LCD display with keypad (L1 option)
2 - TTG display with keypad (L5 option)
3 - Integrated digital LCD display (LS option
replacing L9 option PHASED OUT)
1
