ABB 266MST User Manual

62 OI/266/HART-EN Rev. M | 2600T Series Pressure transmitters
9 Error messages
— Sensor related error messages
Error message Tx LCD message Possible cause Suggested action Tx response
F120.016 Sensor Invalid
The sensor signal is not being updated correctly as a
result of an electronics failure, sensor error or a poorly
connected sensor cable.
Check cable connection,
check sensor and if problem
persists, the sensor must be
replaced.
Analog Signal to
Alarm
F120.016 Sensor Invalid
The sensor model/version is no longer compatible with
the connected electronic version.
The sensor must be replaced.
Analog Signal to
Alarm
F118.017 Sensor Memory Fail Sensor memory corrupted. The sensor must be replaced.
Analog Signal to
Alarm
F114.000 P-dP Sensor Fail
Mechanical damage to the sensor. Loss of fill fluid from
the cell, ruptured diaphragm, broken sensor.
The sensor must be replaced.
Analog Signal to
Alarm
F112.001
Static Pressure
Sensor Fail
The circuitry for the sampling of the static pressure has
failed.
The sensor must be replaced.
Analog Signal to
Alarm
F110.002
Sensor Temperature
Fail
The circuitry for the sampling of the temperature has
failed.
The sensor must be replaced.
Analog Signal to
Alarm
M028.018
NV Sensor Memory
Burn Error
Writings to the sensor non-Volatile Memory was not
successful.
The sensor should be replaced
as soon as possible.
no effect
— Configuration related error messages.
Error message Tx LCD message Possible cause Suggested action Tx response
C088.030
Input Simulation
Active
The P-dP Value produced in output is
derived by the value simulated in input.
Use a HART configurator (DTM - Hand held) to place
device back in to normal operating mode (Remove
the input simulation).
no effect
C088.030
Input Simulation
Active
The Static Pressure Value produced in
output is derived by the value simulated in
input.
Use a HART configurator (DTM - Hand held) to place
device back in to normal operating mode (Remove
the input simulation).
no effect
C088.030
Input Simulation
Active
The Sensor Temperature Value produced
in output is derived by the value simulated
in input.
Use a HART configurator (DTM - Hand held) to place
device back in to normal operating mode (Remove
the input simulation).
no effect
M014.037 Configuration Error
Refer to the Instruction manual to
understand the possible cause of this
error.
Use a HART configurator (DTM - Hand held) to
correct the configuration.
no effect
M020.042 Replace Info
The Electronics or the Sensor have been
changed but the replacement operation
has not been executed.
The replacement operation must be executed: Move
the SW 1 of the electronics in position 1 = Enable
replace mode -Select the SW 2 the element that has
been changed between new Sensor or new
electronics -Power Cycle the device -Move the SW 1
of the electronics in position 0.
no effect
M020.042 Replace Info
The Electronics or the Sensor have been
changed and a replacement operation for
a new sensor has to be executed.
The replacement operation must be executed: Only
the data of the electronics can be copied into the
sensor-Move the SW 1 to Enable replace mode
(1)-Select with the SW 2 to New Sensor (1)-Power
Cycle the device-Move the SW 1 to Disable replace
mode (0).
no effect
M020.042 Replace Info
The Electronics or the Sensor have been
changed.
The replacement has been enabled but
with a wrong direction (SW 2 = 0).
Change the replacement direction (if possible)-The
SW 1 is already set to Enable replace mode (1)-Select
with the SW 2 to New Sensor (1)-Power Cycle the
device-Move the SW 1 to Disable replace mode (0).
no effect
