ABB A100-H Series User Manual

Assembly Instructions / A100-H
3 Weight and transportation of the turbocharger / 
© Copyright 2020 ABB. All rights reserved. HZTL455311P0004_EN Rev.B July 2020
3 Weight and transportation of the
turbocharger
Lifting gear with a sufficient load limit must be used for removing, installing and transport-
ing the turbocharger. The weight specified below applies to the heaviest variant possible.
Depending on the specification, the weight specified on the rating plate may be lower than
the standard value specified here.
Fig.3: Transportation of the turbocharger
Product Weight of complete turbocharger unit [kg]
A130-H 190
A135-H 270
A140-H 460
Table4: Weight of complete turbocharger unit
Page 9 / 21
