ABB A100-H Series User Manual

Assembly Instructions / A100-H
4 Installing the turbocharger / 4.4 Fastening the turbocharger with a
standard nut
© Copyright 2020 ABB. All rights reserved. HZTL455311P0004_EN Rev.B July 2020
4.4 Fastening the turbocharger with a standard nut
u Fit the nuts and tighten them according to variant 1 or 2 in the table below.
Product Through hole in
bearing casing
[mm]
Fixing screws
[mm]
Variant 1: Tightening
torques [Nm] **)
Variant 2: Hy-
draulic pre-ten-
sioning forces [kN]
A130 Ø17 M16 280 110
A135 Ø 21 M20 560 175
A140 Ø 25 M24 960 250
Table6: Tightening torque for standard nuts
**) When the turbocharger is mounted on the engine support, the bolt threads and screw
heads must be lightly oiled (assumed friction coefficient µ = 0.12 for tightening torque)
u Remove the lifting gear.
Page 13 / 21
