Operation Manual / A170-M.. - A175-M..
13 Spare parts / 13.2 Spare part – Illustrations
© Copyright 2020 ABB. All rights reserved. HZTL4033_EN Rev.G December 2020
Required customer spare part set (97070)
For the work described in the Operation Manual, the customer spare part set (97070) is re-
quired. These parts are only available in the complete set.
Customer spare part set
97070 Designation Quantity
25013 Socket screw 1
25014 Washer 1
42012 O-ring 1
42041 Gasket 1
42045 Gasket 2
42059 / 42064 Hexagon-head screw 2
56014 Hexagon-head screw 2
56015 Locking washer 2
57005 Hexagon-head screw 5
61037 Hexagon nut 3
61069 Hexagon-head screw 3
77015 Socket screw 3
77040 O-ring 1
86506 O-ring (speed sensor) 1
Table60: Customer spare part set (97070)
13.2 Spare part – Illustrations
The spare parts lists shown below are only available in English.
