ABB AC 800M Library Object Style Guide

Section 4 Engineering Interface Function Block Example
3BSE042835-600 55
Table 8. Parameter list
Name Data Type Direction Name Data Type Direction
1
Enable bool in
24
PriorityMode bool out
2
Name string[30] in
25
PriorityStart bool in
3
Description string[40] in
26
PriorityStop1 bool in
4
Interlock bool out
27
PriorityStop2 bool in
5
SetAuto bool in
28
PriorityStop2Txt string in
6
AutoMode bool out
29
PriorityStop3 bool in
7
AutoStart bool in
30
PriorityStop3Txt string in
8
AutoStop bool in
31
PriorityStartMan bool in
9
AutoSP1 real in
32
PriorityStopMan bool in
10
ManMode bool out
33
PriorityStopManTxt string in
11
ManModeInit bool in
34
PrioritySP1 real in
12
PanMode bool out
35
OutOfServiceMode bool out
13
SetPan bool in
36
LocMode bool out
14
PanStart bool in
37
IlockStart bool in
15
PanStop bool in
38
IlockStop bool in
16
PanSP1 real in
39
Inhibit bool in
17
GroupStartIn GroupStartStep
Connection
in_out
40
ObjectTest bool in
18
GroupStartMode bool out
41
ScaledSpdAct real out
19
GroupStartILock bool in
42
ScaledTrqAct real out
20
ContinueStartSeq bool in
43
Status DintIO in_out
21
ContinueStartSeqTxt string[40] in
44
ActCurrent DintIO in_out
22
ContinueStopSeq bool in
45
NomCurrent DintIO in_out
23
ContinueStopSeqTxt string[40] in
46
ActSpeed DintIO in_out
