ABB AC 800M

Function Block Example Section 4 Engineering Interface
56 3BSE042835-600
47
ActTorque DintIO in_out
71
TrippedStat bool out
48
Command DintIO in_out
72
ALStateFault dint out
49
SpdRef DintIO in_out
73
AEConfigFault dint in
50
Trq Re f DintIO in_out
74
AESeverityFault dint in
51
TrqSelectorOut DintIO in_out
75
EnableFault bool in
52
WindowCtrlOn DintIO in_out
76
CondNameWarning string[15] in
53
EStop bool in
77
WarningEnabled bool out
54
EStopRamp bool in
78
Alarm bool out
55
UseSP2 bool in
79
AlarmStat bool out
56
ReadyToSwitchOn bool out
80
ALStateWarning dint out
57
Run bool out
81
AEConfigWarning dint in
58
AtSetpoint bool out
82
AESeverityWarning dint in
59
AboveLimit bool out
83
EnableWarning bool in
60
SP2Used bool out
84
CondNameObjectError string[15] in
61
TorqueSP real in
85
ObjErrEnabled bool out
62
FollowerDrive bool in
86
ObjErr bool out
63
WindowControl bool in
87
ObjErrStat bool out
64
TrqSelectorValue int in
88
ALStateObjectError dint out
65
TrqSelectorErr bool out
89
AEConfigObjectError dint in
66
Reset bool in
90
AESeverityObjectError dint in
67
AlarmsDisabled bool out
91
EnableObjectError bool in
68
CondNameTripped string[15] in
92
AlarmsAck bool in
69
FaultEnabled bool out
93
AEClass dint in
70
Tr ip pe d bool out
94
InteractionPar ACStdDrivePar in_out
Table 8. Parameter list (Continued)
Name Data Type Direction Name Data Type Direction
