Section 2 Transmission Media and Components Flat Cable
9ARD000015-600 35
Table 24 provides the various specifications of Flat cable and their corresponding
table numbers.
Table 24. Specifications of Flat Cable and their Corresponding Table Numbers
Characteristics Table Number
Data Pair Specification
Physical
Table 25
Electrical
Table 26
DC Power Specification
Physical
Table 27
Electrical
Table 28
General Specification
Physical
Table 29
Electrical
Table 30
Environmental
Table 31
Table 25. Physical Characteristics of Data Pair Specification for Flat Cables
Physical Characteristics Specification
Conductor pair Size #16 Copper (minimum); 19 strands
minimum (individually tinned)
Insulation diameter 0.110 inches (nominal)
Colors Light Blue
White
Pair Twist/ft N/A
Tape shield over pair N/A
