ABB AC 800M

Section 2 Transmission Media and Components Flat Cable II
9ARD000015-600 43
Table 38. Electrical Characteristic of DC Power Specification for Flat Cable II
Electrical Characteristic Specification
DCR - @ 20° C 6.9 ohms/1000 ft (maximum)
Table 39. Physical Characteristics of General Specification for Flat Cable II
Physical Characteristics Specification
Geometry Flat
Overall braid shield N/A
Drain wire N/A
Outside diameter Width: 10.16 mm +0 mm, -0.5 mm
Height: 2.54 mm +/- 0.06 mm
Roundness Flat
Jacket marking Vendor Name and Certification mark
Table 40. Electrical Characteristic of General Specification for Flat Cable II
Electrical Characteristic Specification
DCR (braid+tape+drain) N/A
