Flat Cable II Section 2 Transmission Media and Components
44 9ARD000015-600
Table 42 lists the topology details of Flat cable II.
Table 41. Environmental Characteristics of General Specification for Flat Cable II
Applicable Environmental
Characteristics
Specification
Agency Certifications
(U.S. and Canada)
To meet local regulatory agencies.
Flexure Specified by vendor (under measurement)
Bend Radius Specified by vendor
Operating ambient temperature -10° C .. +55° C
Storage temperature -20° C .. +65° C
Pull tension 40 lbs maximum
Connector Compatibility FLAT II TRUNK CONNECTOR Female and
male
Topology Compatibility Trunk, Branch
Table 42. Flat Cable II Topology
Data Rate
Max
Cable
Distance
Trunk
Exchange
(Thick Cable)
Cumulative
Drop
Maximum
Drop
125 kb 265 m (1050 ft) N/A 135 m (511 ft) 6 m (20 ft)
250 kb 150 m (574 ft) N/A 48 m (157 ft) 6 m (20 ft)
500 kb 75m (213 ft) N/A 35 m (82 ft) 6 m (20 ft)
