ABB AC 800M

Power Taps Section 2 Transmission Media and Components
52 9ARD000015-600
Table 45 lists the specifications for the Internal Power Drop Conductor.
V- Power conductor
(stranded or solid)
7 inches maximum conductor length. Maximum conductor
resistance of 2.1 milliohms. (Equivalent to 7 inches of 15 AWG).
Minimum conductor equivalent is 16 AWG.
CANH and CANL Signal
conductors (stranded or solid)
7 inches maximum conductor length. Maximum resistance of 4.1
milliohms (equivalent to 7 inches of 18 AWG). Minimum conductor
equivalent at any point is 22 AWG.
Table 45. Internal Power Drop Conductor Specifications
Conductor Description Specification
Drain wire conductor to
grounding terminal
(stranded or solid)
Maximum conductor length of 7 inches. Maximum resistance is
2.1 milliohms (equivalent to 7 inches of 15 AWG). Minimum
allowable conductor at any point is 16 AWG.
V+ and V- Power conductors
(stranded or solid)
12 inches maximum conductor length per leg. Maximum
resistance per leg is (excluding protection) 3.6 milliohms.
(Equivalent to 12” of 15 AWG). Minimum conductor equivalent at
any location is 16 AWG. Any conductor carrying between 8 and
16 amps must be 12 AWG equivalent or larger.
Table 44. Internal Pass Through Conductor Specifications
Conductor Description Specification
