ABB ACS140 - Terminal Interface

8
G Terminal Interface
Warning! Dangerous voltage
Wait 5 minutes after
disconnecting supply
before proceeding. See
User´s Manual
.
ABB
ABB Oy
ACS143-1K6-1
U1 3* 200...240 V U2 3*0..U1
f1 50/60 Hz f2 0..300 Hz
I1 5.3 A I2 4.3 A
S/N 242A0001
to motor
Power output
Warning
Sticker
Protective
Earth
DC Terminals for
optional ACS
braking unit/chopper
Shield
Motor Cable
Red LED
Green LED
1
Power Supply Input
19
Control
Terminals,
see K
DIP-
Switch
