ABB ACS140 - Application Macro Configurations

29
Application Macros
Application Macros are preprogrammed parameter sets. They minimise the
number of different parameters to be set during start-up. The Factory Macro
is the factory-set default macro.
Note! The Factory Macro is intended for applications where there is no
control panel available. If using the Factory Macro with control panel note
that the parameters whose value depend on the digital input DI4 cannot
be modified from the panel.
Parameter Values
Selecting an application macro with parameter 9902
APPLIC MACRO will set all
other parameters (except group 99 start-up data parameters, the parameter
lock 1602 and group 52 serial communication parameters) to their default
values.
Default values of certain parameters depend on the selected macro. These
are listed with the description of each macro. Default values for other
parameters are given in “ACS140 Complete Parameter List” starting on page
39.
Connection Examples
In the following connection examples please note:
• All the digital inputs are connected using negative logic.
• The signal types of analogue inputs AI1 and AI2 are selected with DIP
switches S1:1 and S1:2.
Frequency reference
is given with
DIP switch S1:1 or S1:2
voltage signal (0 - 10 V) off
current signal (0 - 20 mA) on
ON
ON
