15
* Derate ambient temperature to 30 °C or derate P
N
and I
2
to 90 % (see I
2
(8 kHz)).
** Derate ambient temperature to 30 °C and derate P
N
and I
2
to 75 % (see I
2
(16 kHz)).
*** Fuse type: UL class CC or T. For non-UL installations IEC269 gG.
Use 60 °C wire for an ambient temperature of 45 °C or less and use 75 °C wire for
ambient temperature between 45 °C and 50 °C.
Standard 200 V series
Nominal motor P
N
kW 0.75 1.1 1.5 2.2
1~ Input ACS141- 1K6-1 2K1-1 2K7-1 4K1-1
3~ Input ACS143- 1K6-1 2K1-1 2K7-1 4K1-1
Frame size BC D
Nominal ratings
(See H) Unit
Input voltage U
1
V 200 V-240 V ±10 % 50/60 Hz
(ACS141: 1~, ACS143: 3~)
Continuous output
current I
2
(4 kHz)
A 4.3 5.9 7.0 9.0
Continuous output
current I
2
(8 kHz)
A 3.9 5.3 6.3 8.1
Continuous output
current I
2
(16 kHz)
A 3.2 4.4 5.3 6.8
Max. output current I
2 max
(4 kHz)
A 6.5 8.9 10.5 13.5
Max. output current I
2 max
(8 kHz)
A 5.9 8.0 9.5 12.2
Max. output current I
2 max
(16 kHz)
A 4.7 6.5 7.7 9.9
Output voltage U
2
V0 - U
1
3~
Input current I
1
1~ A 10.8 14.8 18.2 22.0
Input current I
1
3~ A 5.3 7.2 8.9 12.0
Switching frequency kHz 4 (Standard)
8 (Low noise *)
16 (Silent **)
Protection limits (See P)
Overcurrent (peak) A 13.8 19.0 23.5 34.5
Overvoltage:
Trip limit V DC 420 (corresponds to 295 V input)
Undervoltage:
Trip limit V DC 200 (corresponds to 142 V input)
Overtemperature
°C90
(heat sink)
95
(heat sink)
Max. wire sizes
Max. motor cable length m 75 75 75 75
Power terminals mm
2
4 single core / torque 0.8 Nm
Control terminals mm
2
0.5 - 1.5 (AWG22...AWG16) / torque 0.4 Nm
Line fuse 1~ ***
ACS141-
A 16 162025
Line fuse 3~ ***
ACS143-
A 6 10 10 16
Power losses
Power circuit W 27 39 48 70
Control circuit W 17 18 19 20
