90
Table 10 Maximum motor cable lengths with input filter ACS100-FLT-D, -E
or ACS140-FLT-D and switching frequency 4 kHz.
For 1-phase converters ACS141-xKx-1 two chokes ACS-CHK-A or ACS-
CHK-C are supplied in the filter package. The motor cable including the
shield must be fed through the hole in the choke. Also all control cables and
the control panel cable, if present, must be fed through another choke. For 3-
phase converters ACS143-xKx-3 one choke ACS-CHK-A is supplied in the
filter package and the motor cable including the shield must be fed through
the hole in the choke. The cable lengths between the converter and the
chokes must be at maximum 50 cm.
For types ACS141-2K1-1, ACS141-2K7-1 and ACS141-4K1-1 the control
panel, if present, must be mounted on the converter front cover.
Converter type
ACS100-FLT-D ACS100-FLT-E
4kHz 4kHz
ACS141-K75-1 5 m -
ACS141-1K1-1 5 m -
ACS141-1K6-1 5 m -
ACS141-2K1-1 - 5 m
ACS141-2K7-1 - 5 m
ACS141-4K1-1 - 5 m
Converter type
ACS140-FLT-D
4kHz
ACS143-xKx-3 5 m
