ACS550 User’s Manual 53
Start-Up
Complete Parameter List for ACS550
The following table lists all parameters. Table header abbreviations are:
•S = Parameters can be modified only when the drive is stopped.
• User = Space to enter desired parameter values
Some values depend on the “construction” as indicated in the table by “01:” or “U1:”.
Refer to the type code on the drive, for example ACS550-01..
Code Name Range Resolution Default User S
Group 99: Start-Up Data
9901
LANGUAGE 0…13 1 0
9902
APPLIC MACRO -3…8 1 1 9
9904 MOTOR CTRL MODE 1=VECTOR: SPEED, 2=VECTOR: TORQUE,
3=
SCALAR: SPEED
13 9
9905
MOTOR NOM VOLT 115…345 V 1 V 230 V 9
01: 200…600 V /
U1: 230…690 V
1 V 01: 400 V /
U1: 460 V
9
9906 MOTOR NOM CURR 0.2*I
2hd
…2.0*I
2hd
0.1 A 1.0*I
2hd
9
9907 MOTOR NOM FREQ 10.0…500 Hz 0.1 Hz 01: 50 Hz /
U1: 60 Hz
9
9908
MOTOR NOM SPEED 50…30,000 rpm 1 rpm Size dependent 9
9909
MOTOR NOM POWER 0.2…3.0*P
hd
01: 0.1 kW /
U1: 0.1 HP
1.0 * P
hd
9
9910
MOTOR ID RUN 0 = OFF, 1= ON 10 9
Group 01: Operating Data
0102
SPEED 0…30000 rpm 1 rpm -
0103 OUTPUT FREQ 0.0…500.0 Hz 0.1 Hz -
0104
CURRENT 0…2.0*I
2hd
0.1 A -
0105
TORQUE -200…200% 0.1% -
0106 POWER -2.0…2.0*P
hd
0.1 kW -
0107
DC BUS VOLTAGE 0…2.5*V
dN
1 V -
0109
OUTPUT VOLTAGE 0…2.0*V
dN
1 V -
0110
DRIVE TEMP 0…150 °C0.1 °C-
0111
EXTERNAL REF 1 0…30000 rpm / 0…500 Hz 1 rpm / 0.1 Hz -
0112
EXTERNAL REF 2 0…100% (0…600% for torque) 0.1% -
0113
CTRL LOCATION 0 = local, 1 = ext1, 2 = ext2 1 -
0114
RUN TIME (R) 0…9999 h 1 h 0 h
0115
KWH COUNTER (R) 0…9999 kWh 1 kWh -
0116
APPL BLK OUTPUT 0…100% (0…600% for torque) 0.1% -
0118
DI 1-3 STATUS 000…111 (0…7 decimal) 1 -
0119
DI 4-6 STATUS 000…111 (0…7 decimal) 1 -
0120
AI1 0…100% 0.1% -
0121
AI2 0…100% 0.1% -
0122
RO 1-3 STATUS 000…111 (0…7 decimal) 1 -
0123
RO 4-6 STATUS 000…111 (0…7 decimal) 1 -
0124
AO1 0…20 mA 0.1 mA -
0125
AO2 0…20 mA 0.1 mA -
