6 Start up and use
Set the drive parameters
Open Diagnostics
1. Open the Main menu from the Home view.
2. Scroll to Parameters and press the OK button to open the
submenu.
3. Select the complete parameters list, or
4. Select the modified parameters list with the arrow button and
press the OK button.
5. The parameters are shown in respective groups. The first
two digits of the parameter represent the parameter group.
For example, parameters starting with 30 are in the Limits
group.
See the relevant drive firmware manual for the related
parameters.
1. Open the Main menu from the Home view.
2. Scroll to Diagnostics and press the OK button to open the
submenu.
3. Select the warning or fault list with the arrow button and
press the OK button.
See the relevant drive firmware manual for the related
warnings and faults.
