400 Parameters
60.27 M/F status supv
mode sel 1
In the D2D master, parameters 60.27 M/F status supv mode
sel 1 and 60.28 M/F status supv mode sel 2 specify the mode
of follower status word monitoring. Each follower can
individually be set to be monitored continuously, or only when
it is in stopped state.
This parameter selects the mode of status word monitoring of
followers 1…16.
-
0000h…FFFFh D2D status supervision mode selection 1. 1 = 1
60.28 M/F status supv
mode sel 2
Selects the mode of status word monitoring of followers
17…32.
-
0000h…FFFFh D2D status supervision mode selection 2. 1 = 1
60.31 M/F wake up delay Defines a wake-up delay during which no master/follower
communication faults or warnings are generated. This is to
allow all drives on the master/follower link to power up.
The master cannot be started until the delay elapses or all
monitored followers are found to be ready.
60.0 s
0.0 … 180.0 s Master/follower wake-up delay. 10 = 1 s
No. Name/Value Description Def/FbEq16
Bit Name Description
0 Follower 1 0 = Status of follower 1 is monitored continuously.
1 = Status of follower 1 is monitored only when it is in stopped state.
1 Follower 2 0 = Status of follower 2 is monitored continuously.
1 = Status of follower 2 is monitored only when it is in stopped state.
…… …
15 Follower 16 0 = Status of follower 16 is monitored continuously.
1 = Status of follower 16 is monitored only when it is in stopped state.
Bit Name Description
0 Follower 17 0 = Status of follower 17 is monitored continuously.
1 = Status of follower 17 is monitored only when it is in stopped state.
1 Follower 18 0 = Status of follower 18 is monitored continuously.
1 = Status of follower 18 is monitored only when it is in stopped state.
…… …
15 Follower 32 0 = Status of follower 32 is monitored continuously.
1 = Status of follower 32 is monitored only when it is in stopped state.
