Page #23 background image
AO2000-LS25 LASER ANALYZERS | OI/AO2000-LS25-EN REV. D 23
CSA certification, gas analyzer
CSA Class I Division 2 Groups A, B, C, D, Temperature class T4,
electrical equipment
Applicable requirements:
CAN/CSA C22.2 No. 0-M91 (R2001): General Requirements
Canadian Electrical Code, Part II
CSA standard C22.2 No. 142-M1987:
Process Control Equipment
CSA standard C22.2 No. 213-M1987:
Non-lncendive Electrical Equipment for Use in Class I,
Division 2 Hazardous Locations
UL standard No. 916-2007: Energy Management
Equipment
ANSI/ISA-12.12.01-2010:
Non-lncendiveElectrical Equipment for Use in Class I
and II, Division 2 and Class III, Divisions 1 and 2 Hazardous
(Classified) Locations
Certificate no.:
1105720
CSA certification, power supply unit
The power supply unit has its own CSA approval, which is
registered under UL File e213613 (Class I, Division 2, group A, B, C
& D, temp. Class T4).
Ambient conditions
Operating temperature
20 °C to +55 °C
Storage temperature
20 °C to +55 °C
IP rating
Designed for outdoor applications (all modules IP 66-
certified).
IP rating is not part of the CSA certification
Degree of contamination
2
Installation category (overvoltage category)
II
Installation height
2000 m
Air humidity
0 to 95 %
Electrical data
Power supply
Power supply unit (input)
85 to 264 V AC, 50 / 60 Hz
Power supply unit (output)
24 V DC, maximum 5 A
Transmitter unit (input)
18 to 32 V DC, maximum 20 W
Interfaces
Service interface
RS232 according to EIA/TIA-232 and V.28/V.24
Level: max. ±15 V.
Current (short-circuit): max. ±60 mA
Ethernet interface
Protocol 10/100Base-T
Max. voltage: ±2.5V
Safety instructions
DANGER
Explosion hazard
Failure to follow safety instructions may cause ignition of
hazardous atmosphere resulting in serious personal injury
and/or property damage.
WARNING
Loss of Ex-approval!
Loss of Ex approval due to replacement of components in
devices for use in potentially explosive atmospheres.
Devices for use in potentially explosive atmospheres may
be serviced and repaired by qualified ABB personnel only.
For measuring devices for potentially explosive
atmospheres, observe the relevant operator guidelines.
