ABB ATS021 - DIN-rail Mounting Procedure

21
1SDH000759R0002, L4106
Installation and operating instructions, ATS021
KA00481
O
N
DIP
1
2
3
4
3
4
35mm
EN 50022
3
2
1
174
9,5
114
115
97
145
5
Ø
19,5
KA00482
Remove
KA00484
1 2
3
5.2.2 Automatic transfer switch ATS021, DIN-rail mounting
The automatic transfer switch ATS021 can be mounted on the 35 mm DIN-rail, see the Figure 5.4. Door
drilling, if needed, according to Figure 5.4.
Figure 5.4 Automatic transfer switch ATS021, DIN-rail mounting
5. Installation
