ABB CL-LMR 18AC2 Series User Manual

Wiring with the logic relay
142
1SVC 440 795 M0100
Power failure example
The power is removed between 15:00 and 17:00. The relay
drops out and remains off, even after the power returns,
since the first off time was at 16:00.
24 hour switching example
The time switch is to switch for 24 hours. Switch-on time at
00:00 on Monday and switch-off time at 00:00 on Tuesday.
h
On and off times always follow the channel which
switches first.
Ö4 A +
D MO-SU
ON 12:00
OFF 16:00
Ö4 B +
D MO-SU
ON 12:00
OFF 18:00
h
When switched on, the logic relay always updates the
switching state on the basis of all the available switching
time settings.
Ö1 A +
D MO
ON 00:00
OFF --:--
Ö1 B +
D TU
ON --:--
OFF 00:00
