Technical data
259
1SVC 440 795 M0100
CL-LSR...AC2, CL-LER.18AC2, CL-LMR...AC2
Rated voltage L (sinusoidal) 24 V AC 24 V AC
At state ”0”
0 to 6 V AC 0 to 6 V AC
At state ”1” (I7, I8)
> 8 V AC, > 11 V DC
(I1 to I6, I9 to I12)14 to
26.4 V AC
(I7, I8, I11, I12)
> 8 V AC, > 11 V DC
(I1 to I6, I9, I10) 14 to
26.4 V AC
Rated frequency
50/60 Hz 50/60 Hz
Input current for state “1”
I1 to I6 (CL-LMR also I9 to I10)
4 mA at 24 V AC 50 Hz 4 mA at 24 V AC 50 Hz
Input current for state “1”
I7, I8 (CL-LMR also I11, I12)
2 mA at 24 V AC 50 Hz,
2 mA at 24 V DC
2 mA at 24 V AC 50 Hz,
2 mA at 24 V DC
Delay time for 0 to 1 and 1 to 0 for I1 to I8, CL-LMR also I9 to I12
Debounce ON 80 ms (50 Hz), 66B/c ms (60 Hz) 80 ms (50 Hz), 66B/c ms (60 Hz)
Debounce OFF 20 ms (50 Hz), 16B/c ms (60 Hz) 20 ms (50 Hz), 16B/c ms (60 Hz)
Max. permissible cable length (per input)
I1 to I8 (CL-LMR also I9 to I10)
Normally 40 m Normally 40 m
CL- LSR...AC1 CL-LMR...AC1
CL-LSR...AC2 CL-LER.18AC2,
CL-LMR...AC2
Digital inputs 115/230 V AC
Quantity 8 12
Status display LCD (if provided) LCD (if provided)
Potential isolation
To power supply No No
Between each other No No
To the outputs Yes Yes
Rated voltage L (sinusoidal)
At signal ”0” 0 to 40 V AC 0 to 40 V AC
At signal ”1” 79 to 264 V AC 79 to 264 V AC
Rated frequency 50/60 Hz 50/60 Hz
