ABB CL-LMR 18AC2 Series User Manual

Technical data
263
1SVC 440 795 M0100
Delay time from 1 to 0
Debounce ON 20 ms 20 ms 20 ms
Debounce OFF • Normally 0.4 ms
(I1 to I6)
• Normally 0.2 ms
(I7, I8)
Normally 0.4 ms
(R1 to R12)
• Normally 0.4 ms
(I1 to I6, I9, I10)
• Normally 0.2 ms
(I7, I8, I11, I12)
Cable length (unshielded)
100 m 100 m 100 m
CL-LSR...DC2,
CL-LST...DC2
CL-LER...DC2,
CL-LET...DC2
CL-LMR...DC2,
CL-LMT...DC2
High-speed counter inputs, I1 to I4 CL-LSR...DC1,
CL-LSR...DC2,
CL-LST...DC2,
CL-LMR...DC1,
CL-LMR...DC2,
CL-LMT...DC2
Number
4
Cable length (shielded) m 20
High-speed up and down counter
Counting frequency kHz <1
Pulse shape Square
Pulse pause ratio 1:1
Frequency counter
Counting frequency kHz < 1
Pulse shape Square
Pulse pause ratio 1:1
