ABB CL-LMR 18AC2 Series User Manual

Appendix
264
1SVC 440 795 M0100
CL-LSR...AC1,
CL-LSR...DC1,
CL-LSR...DC2,
CL-LST...DC2
CL-LMR...AC1,
CL-LMR...DC1,
CL-LMR...DC2,
CL-LMT...DC2
Analog inputs I7, I8, I11, I12
Quantity 2 4
Potential isolation
To power supply No No
From the digital inputs No No
To the outputs Yes Yes
Input type
DC voltage DC voltage
Signal range 0 to 10 V DC 0 to 10 V DC
Resolution analog 10 mV 10 mV
Resolution digital 0.01 (10-bit, 1 to 1023) 0.01 (10-bit, 0 to 1023)
Input impedance 11.2 kO 11.2 kO
Accuracy
Two CL devices g 3 % of actual value g 3 % of actual value
Within a single device g 2 % of actual value (I7, I8), g 0,12 V
Conversion time, analog/digital Debounce ON: 20 ms
Debounce OFF: every cycle
Input current at 10 V DC 1 mA 1 mA
Cable length (shielded) 30 m 30 m
