Installation
36
1SVC 440 795 M0100
Connect digital AC inputs to the basic unit
Figure 12: Connect digital inputs CL-AC1 and CL-AC2
Connect digital AC inputs to the expansion unit
Figure 13: Connect digital inputs CL-LER.18AC2
l1 I2 I7
L
N
LNN
F1
L
N
R10R9R8R7R6R5R4R3R2R1E+ E-
R11
R12 NNL
F1
