Installation
44
1SVC 440 795 M0100
Analog setpoint potentiometer,
CL-AC1,CL-DC1,CL-DC2
Figure 20: Analog setpoint potentiometer with own power feed
Use a potentiometer with a resistance of 1 k, e. g. 1 k,
0.25 W.
Analog setpoint potentiometer CL-DC2
Figure 21: Analog setpoint potentiometer with 24 V DC power feed
~
0 V
+12 V
I7+...V
L
0 V
N
0 V
N
F1
L01
L01
1.3 kO/0.25 W
1 kO/0.25 W
0 V 0 V I7+...V
DC : +24 V
DA : +12 V
F1
