ABB CL-LMR 18AC2 Series

Connecting the inputs
45
1SVC 440 795 M0100
Brightness sensor CL-AC1, CL-DC1, CL-DC2
Figure 22: Connection of a brightness sensor, analog input
Temperature sensor, CL-DC1, CL-DC2
Figure 23: Connection of the temperature sensor, analog input
0 V
0...10 V
12 V
~
0 V
+12 V
I7+...V
L
0 V
N
0 V
N
F1
+24 V
–0 V
Out
0...10 V
–35...55 ˚C
I7+...V
L
0 V
N
0 V
N
F1
