ABB CL-LMR 18AC2 Series User Manual

Wiring with the logic relay
94
1SVC 440 795 M0100
X Complete the circuit diagram up to CC1.
CC1 is the count coil of the counter 1 function relay.
X Move the cursor onto the 1 of CC1 and press OK.
The parameter set for the counter is displayed.
X Press the cursor button until the cursor is on the plus sign
on the right of the S (setpoint).
X Press the OK button.
X Press the í button.
X Use í to move the cursor onto the tens digit.
X Use Í Ú to modify the value of the digit.
X Confirm the value input with OK.
X Press ESC to return to the circuit diagram, the setpoint
0010 will be stored.
I5-------CC1
h
Press OK to call up the logic relay parameter display.
C1 N +
S +0
C1 N +
S 00000
C1 N +
S 00010
C1 N +
S 00010
I5-------CC1
ê
