Function relays
95
1SVC 440 795 M0100
X Enter the circuit diagram up to coil TT1 of the timing
relay. Set the parameter for
T1.
The timing relay operates as a flash relay. The CL symbol for
the flasher/blink relay is
Ü and is set at the top left of the
parameter display.
S means here the time base second.
X Select the Ü symbol by pressing the Ú button.
X Use the í to move to the first time setpoint I1.
X Press the OK button.
X Press the í button.
X Use the Í Ú ú í buttons to enter the value 01.000.
X Confirm with OK.
The time setpoint
I1 for the pause time is 1 s
h
The logic relay has specific parameter displays for function
relays. The meaning of these parameters is explained
under each relay type.
I5-------CC1
I6-------RC1
C1-------TT1
T1 X S +
I1 +0
I2 +0
T:
T1 Ü S +
I1 +0
I2 +0
T:
T1 Ü S +
I1 +0
I2 +0
T:
T1 Ü S +
I1 00.000
I2 +0
T:
T1 Ü S +
I1 01.000
I2 +0
T:
