ABB Comem OLI - Comem OLI22; Eoli22 (Radial); Comem OLI22; Eoli22 (Axial)

5
TRANSFORMER COMPONENTS
2.3.3 Comem OLI22 / Comem eOLI22 (radial)
Figure 5
—
2. Drawings
2.3.4 Comem OLI22 / Comem eOLI22 (axial)
Figure 6
“4 HOLES” MOUNTING FLANGE MAY BE
DESIGNED IN ACCORDANCE WITH CUSTOMER’S
NEED: UPON REQUEST, SEVERAL HOLE
PATTERNS ARE AVAILABLE.
NOTE
