ControlMaster CMF160 | Universal process indicator, fieldmount | DS/CMF160–EN Rev. B 17
Overall dimensions
Dimensions in mm (in.)
Transmitter
Pipe mount option
Wall mount option
Panel mounting
213 (8.38)
194
(7.64)
Cable gland kit (optional)
98 (3.85)
66 (2.6)
170 (6.7) max.
Pipe diameters:
max. 62 (2.44) / min. 45 (1.77)
Pipe-mount
kit (optional)
Vertical pipe configuration
Horizontal pipe configuration
* To DIN43700
**150 mm (6 in.) if (optional) cable glands fitted
200 (7.87)
62
(2.44)
66
(2.40)
Ø6.4
(0.25)
Fixing centers
Fixing centers
Cable gland kit (optional)
35
(1.4)
92
(3.6)
40 (1.57)**
40 (1.57)
186
+1.1
–0
(7.32 )
+0.04
–0
186
+1.1
–0
(7.32 )
+0.04
–0
Mounting panel – maximum thickness 6 (0.236)
Panel cut-out dimensions*
