Wall-/Pipe Mounted Universal Process Indicator
C160
DS/C160–EN Rev. I
6
3
4
14
15
*
RTD
THC
+
–
+
–
+
–
mA
V/mV
+
–
Tx
* Fit 100Ω resistor supplied
85 to 265V AC
Mains Supply
Relay 1
N/C
CN/O
Relay 2
TX–
+
–
1 2 14 15
L
N
16 17 18 19 20 21 22 23 24
N/C
C
N/O
Digital
input
3 4 5 6 7 8 9 10 11 12 13
TxPSU
RTD
(–ve) Analog Output
Analog/Logic Output (+ve)
TX+ RX–
RX+C
(–ve) Logic Output
+ –
24V DC Supply
– +
Relay 3
N/O C N/C
RS485
Overall Dimensions
68 (2.68)
214
(8.43)
232
(9.13)
Fixing Centers
68 (2.68)
214
(8.43)
232
(9.13)
Fixing Centers
42
(1.65)
61 (2.375) O.D.
Vertical or Horizontal Post
(Kit Part No. 4600/0138)
Allowance for
Cable Bends
160 (6.3)
250
(9.84)
69 (2.72)
Fixing
Centers
200 (7.9)
3 Fixing Holes
6.5 (0.25) Dia.
Dimensions in mm (in.)
Electrical Connections
