12 CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. H
… 2 Use in potentially explosive atmospheres
… Ex marking
cFMus
Note
• A specific marking applies, depending on the design.
• ABB reserves the right to modify the Ex-marking. Refer to the name plate for the exact marking.
Model number for use in Division 2 Ex marking
FCa4c – F2Y0fghijD
Integral mount design with dual-compartment housing
Certificate: FM18US0160X
NI: CL I,II,III Div 2, GPS ABCDEFG, T6…T1
CL I, ZN 2, AEx ec IIC T6…T1
CL I, ZN 2, Ex ec IIC T6...T1
See handbook for temperature class
information
Certificate: FM18CA0073X
DIP: CL II,III, Div 1, GPS EFG, T6
ZN 21, AEx ia tb IIIC T80°C
ZN21,Ex ia tb IIIC T80°C
FCa4c – F2efghijY
Sensor in remote mount design with dual-compartment housing
Design in accordance with ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘Dual Seal Device’ (option TE2)
FCT4c – F2R
Transmitter in remote mount design with dual-compartment housing
FCT4c – F2W
Transmitter in remote mount design with single-compartment
housing
Model number for use in Division 1 Ex marking Certificate
FCa4c – F1Y0fghijDx (x = 1 to 4)
Integral mount design with dual-compartment housing
XP-IS: CL I, Div 1, GPS ABCD,T6…T1 (USA)
XP-IS: CL I, Div 1, GPS BCD,T6…T1 (CAN)
DIP: CL II,III, Div 1, GPS EFG,T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN21, AEx ia tb IIIC T80°C (USA)
CL I, ZN 1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21, Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
cFMus:
3050239
FCa4c – F1Y0fghijDx (x = 5 to 8)
Integral mount design with dual-compartment housing
(Explosionproof ‘XP’).
Design in accordance with ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘Dual Seal Device’ (option TE2)
FCa4c – F1efghijY
Sensor in remote mount design with dual-compartment housing
XP-IS: CL I, Div 1, GPS BCD T6…T1 (USA)
DIP: CL II,III, Div 1, GPS EFG,T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN 21, AEx ia tb IIIC T80°C (USA)
CL I, ZN 1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21, Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
Design in accordance with ANSI / ISA 12.27.01 as ‘Single Seal Device’
or as ‘Dual Seal Device’ (option TE2)
FCT4c – F1Rx (x = 1 to 4)
Transmitter in remote mount design with dual-compartment housing
XP-IS: CL I, Div 1, GPS BCD,T6…T1 (USA) XP-IS: CL I, Div 1, GPS
BCD,T6…T1 (CAN)
DIP: CL II,III, Div 1, GPS EFG, T6
CL I, ZN 1, AEx db ia IIB+H2 T6…T1 (USA)
ZN 21, AEx ia tb IIIC T80°C (USA)
CL I, ZN 1, Ex db ia IIB+H2 T6…T1 (CAN)
ZN21,Ex ia tb IIIC T80°C (CAN)
See handbook for temperature class information and installation
drawing 3KXF000028G0009
FCT4c – F1Rx (x = 5 to 8)
Sensor in remote mount design with dual-compartment housing
(Explosionproof ‘XP’).
