CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. H 77
Basic Setup
The device can be factory parameterized to customer specifications upon request. If no customer information is available, the device
is delivered with factory settings.
Settings for the most common parameters are summarized in the ‘Easy Setup’ menu.
This menu is the quickest way to perform the initial configuration of the device.
For information on navigating through the transmitter menu, see Menu navigation on page 81.
For a detailed description of all menus / parameters see Parameter description in the operating instruction on page 86.
Menu: Easy Setup
Menu / parameter Description
Easy Setup
Language Selection of menu language.
Unit Massflow Qm Selection of the unit for mass flow rate (for example for the Q
m
Max / Q
m
MaxDN parameters and for the corresponding
process value).
Unit Volumeflow Qv Selection of the unit for volume flow rate (for example for the Q
v
Max / Q
v
MaxDN parameters and for the corresponding
process value).
Unit Density Selection of the unit for the density (e.g. for the associated parameters and the corresponding process values).
Unit Temperature Selection of unit for temperature (e.g. for the associated parameters and the corresponding process values).
Unit Mass Totalizer Selection of the unit for the mass counters and the pulse outputs.
Unit Vol. Totalizer Selection of the unit for the volume totalizers and the pulse outputs.
Curr.Out 31 / 32 / Uco Selection of the process value issued via the current output.
The current outputs V1 / V2 and V3 / V4 are only available if the corresponding plug-in cards are present!
Curr.Out V1/V2
Curr.Out V3/V4
Dig.Out 41 / 42 Mode Selection of the operating mode for the digital output 41 / 42.
• Off: Digital output 41 / 42 deactivated.
• Logic: Digital output 41 / 42 as a binary output (e.g. as an alarm output).
• Pulse: Digital output 41 / 42 as a pulse output. In pulse mode, pulses per unit are output (e.g. 1 pulse per m
3
).
• Frequency: Digital output 41 / 42 as a frequency output. In frequency mode, a frequency is issued that is proportional to
the flow rate. The maximum frequency can be configured in accordance with the upper range value.
