CoriolisMaster FCB400, FCH400 CORIOLIS MASS FLOWMETER | CI/FCB400/FCH400-EN REV. H 21
Type of protection ‘e’ / ‘XP’ ‘ia’ / ‘IS’
Inputs and outputs with optional plug-in cards U
M
[V]
I
M
[A]
U
O
[V]
U
I
[V]
I
O
[mA]
I
I
[mA]
P
O
[mW]
P
I
[mW]
C
O
[nF]
C
I
[nF]
C
OPA
[nF]
C
IPA
[nF]
L
O
[mH]
L
I
[mH]
Current output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30 0.1 27.8 30 119 30 826 225 29 29 117 117 0.4 0.4
Current output V1 / V2, passive**
Current output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30 0.1 — 30
—
68 — 510 — 45 — 59
—
0.27
Digital output V3 / V4, active*
Terminals V3 / V4 and V1 / V2*
30 0.1 27.8 30 119 68 826 225 17 17 31 31 0.4 0.4
Digital output V1 / V2, passive**
Digital output V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30 0.1 — 30
—
30 — 225 — 13 — 16
—
0.27
Digital input V3 / V4, active*
Terminals V3 / V4 and V1 / V2
30 0.1 27.8 30 119 3.45 826 25.8 17 17 31 31 0.4 0.4
Digital output V1 / V2, active***
Digital output V3 / V4, active***
Terminals V1 / V2** or V3 / V4
30 0.7 — —
—
——
—
————
—
—
Digital input V1 / V2, passive**
Digital input V3 / V4, passive**
Terminals V1 / V2** or V3 / V4**
30 0.1 — 30
—
3.45 — 25.8 — 13 — 16
—
0.27
Modbus® / PROFIBUS DP®
Terminals V1 / V2
30 0.1 4.2 4.2 150 150 150 150 1.5 1.5 6 6 0.14 0.14
* Only in conjunction with additional ‘24 V DC loop power supply (blue)’ plug-in card in slot OC1.
** The terminal assignment depends on the model number or the slot assignments. For connection examples, see Connection examples on page 53.
*** Not available as intrinsically safe version.
