II F 2-26
3ADW000072R0501_DCS600_System_description_e_e
Converter I
DC
[A] Const. Filter type for y=4 Filter type for y= 5 Filter type for y=6 or 7
type
DCS60x-0025-y1 25A C1a NF3-440-25 NF3-500-25 ---
DCS60x-0050-y1 50A C1a NF3-440-50 NF3-500-50 ---
DCS60x-0075-y1 75A C1a NF3-440-64 NF3-500-64 ---
DCS60x-0100-y1 100A C1b NF3-440-80 NF3-500-80 ---
DCS60x-0140-y1 140A C1b NF3-440-110 NF3-500-110 ---
DCS60x-0200-y1 200A C2a NF3-500-320 NF3-500-320 ---
DCS60x-0250-y1 250A C2a NF3-500-320 NF3-500-320 ---
DCS60x-0270-61 250A C2a NF3-500-320 NF3-500-320 NF3-690-600 ➀
DCS60x-0350-y1 350A C2a NF3-500-320 NF3-500-320 ---
DCS60x-0450-y1 450A C2a NF3-500-600 NF3-500-600 NF3-690-600 ➀
DCS60x-0520-y1 520A C2a NF3-500-600 NF3-500-600 ---
DCS60x-0680-y1 680A C2b NF3-500-600 NF3-500-600 ---
DCS601-0820-y1 740A C2b NF3-500-600 NF3-500-600 ---
DCS602-0820-y1 820A C2b NF3-690-1000 ➀ NF3-690-1000 ➀ ---
DCS60x-1000-y1 1000A C2b NF3-690-1000 ➀ NF3-690-1000 ➀ ---
DCS60x-0903-y1 900A A5 NF3-690-1000 ➀ NF3-690-1000 ➀ NF3-690-1000 ➀
DCS60x-1203-y1 1200A A5 NF3-690-1000 ➀ NF3-690-1000 ➀ NF3-690-1000 ➀
DCS60x-1503-y1 1500A A5 NF3-690-1600 ➀ NF3-690-1600 ➀ NF3-690-1600 ➀
DCS60x-2003-y1 2000A A5 NF3-690-1600 ➀ NF3-690-1600 ➀ NF3-690-1600 ➀
≤ 3000A A6 NF3-690-2500 ➀ NF3-690-2500 ➀ NF3-690-2500 ➀
➀ Filter only available on request
Three - phase filters
EMC filters are necessary to fulfil the standard for
emitted interference if a converter shall be run at a
public low voltage line, in Europe for example with 400
V between the phases. Such lines have a grounded
neutral conductor. ABB offers suitable three - phase
filters for 400 V and 25 A...600 A and 500 V filters for
440 V lines outside Europe.
Converter type of dc current Filter type
field supply unit U
max
= 250 V
[A]
SDCS-FEX-1 6 NF1-250-8
SDCS-FEX-2A 8 NF1-250-8
SDCS-FEX-2A 16 NF1-250-20
DCF 503A-0050 50 NF1-250-55
DCF 504A-0050 50 NF1-250-55
further filters for 12 NF1-250-12
30 NF1-250-30
➊ The filters can be optimized for the real field currents: I
Filter
=
I
Field
➊
Filter in a grounded line (earthed TN or TT
network)
The filters are suitable for grounded lines only, for
example in public European 400 V lines. According to
EN 61800-3 filters are not needed in insulated indus-
trial lines with own supply transformers. Furthermore
they could cause safety risks in such floating lines (IT
networks).
Single - phase filters for field supply
Many field supply units are single - phase converters for
up to 50 A excitation current. They can be supplied by
two of the three input phases of the armature supply
converter. Then a field supply unit does not need its
own filter.
If the phase to neutral voltage shall be taken (230 V in
a 400 V line) then a separate filter is necessary. ABB
offers such filters for 250 V and 6...30 A.
The filters can be optimized for the real motor currents:
I
Filter
= 0.8 • I
MOT max
; the factor 0.8 respects the current
ripple.
Lines with 500 V to 1000 V are not public. They are
local lines inside factories, and they do not supply
sensitive electronics. Therefore converters do not need
EMC filters if they shall run with 500 V and more.
