3ADW000072R0501_DCS600_System_description_e_e
Converter type y → y=4 (400 V) y=5 (500 V) y=6 (600 V) y=7 (690 V)
x=1 → 2-Q I
DC
[A] I
AC
[A] P [kW] P [kW] P [kW] P [kW]
x=2 → 4-Q 4Q 2Q 4Q 2Q 4Q 2Q 4Q 2Q 4Q 2Q 4Q 2Q
DCS60x-0025-y1 25 25 20 20 10 12 13 15
DCS60x-0050-y1 50 50 41 41 21 23 26 29
DCS60x-0050-61 50 50 41 41 31 35
DCS60x-0075-y1 75 75 61 61 31 35 39 44
DCS60x-0100-y1 100 100 82 82 42 47 52 58
DCS60x-0110-61 110 100 90 82 69 70
DCS60x-0140-y1 140 125 114 102 58 58 73 73
DCS60x-0200-y1 200 180 163 147 83 84 104 104
DCS60x-0250-y1 250 225 204 184 104 105 130 131
DCS60x-0270-61 270 245 220 200 169 172
DCS60x-0350-y1 350 315 286 257 145 146 182 183
DCS60x-0450-y1 450 405 367 330 187 188 234 235 281 284
DCS60x-0520-y1 520 470 424 384 216 219 270 273
DCS60x-0680-y1 680 610 555 500 282 284 354 354
DCS60x-0820-y1 820 740 670 605 340 344 426 429
DCS60x-1000-y1 1000 900 820 738 415 418 520 522
DCS60x-0903-y1 900 900 734 734 563 630 648 720
DCS60x-1203-y1 1200 1200 979 979 498 558 624 696
DCS60x-1503-y1 1500 1500 1224 1224 623 698 780 870 938 1050 1080 1200
DCS60x-2003-y1 2000 2000 1632 1632 830 930 1040 1160 1400 1600
DCF60x-0025-y1 25 25 20 20 10 12 13 15
DCF60x-0050-y1 50 50 41 41 21 23 26 29
DCF60x-0075-y1 75 75 61 61 31 35 39 44
DCF60x-0100-y1 100 100 82 82 42 47 52 58
DCF60x-0200-y1 200 180 163 147 83 84 104 104
DCF60x-0350-y1 350 315 286 257 145 146 182 183
DCF60x-0450-y1 450 405 367 330 187 188 234 235
DCF60x-0520-y1 520 470 424 384 216 219 270 273
Table 2.2/3: Table of DCS 600 / DCF 600 units - construction types C1, C2, A5
Converter type y → y=4 (400 V) y=5 (500 V) y=6 (600 V) y=7 (690 V) y=8 (790 V) y=9 (1000V) y=1 (1190V)
I
DC
[A] I
AC
[A] P [kW] P [kW] P [kW] P [kW] P [kW] P [kW] P [kW] ➀
2-Q converters
DCS601-1903-y1 1900 1550 1740
DCS601-2053-y1 2050 1673 1190 1430 1640
DCS601-2503-y1 2500 2040 1160 1450 1750 2000 2300
DCS601-3003-y1 3000 2448 1395 1740 2090 2400 2750
DCS601-2053-y1 2050 1673 2390
DCS601-2603-y1 2600 2121 3030
on request
DCS601-3303-y1 3300 2693 1540 1925 2310 2660 3040 3850
on request
DCS601-4003-y1 4000 3264 1870 2330 2800 3220 3690 4670
on request
DCS601-4803-y1 4800 3917 3360 3860 4420
DCS601-5203-y1 5200 4243 2430 3030
4-Q converters
DCS602-1903-y1 1900 1550 1560
DCS602-2053-y1 2050 1673 1070 1280 1470
DCS602-2503-y1 2500 2040 1040 1300 1560 1800 2060
DCS602-3003-y1 3000 2448 1250 1560 1880 2150 2470
DCS602-2053-y1 2050 1673 2390
DCS602-2603-y1 2600 2121 3030
on request
DCS602-3303-y1 3300 2693 1375 1720 2060 2370 2720 3440
on request
DCS602-4003-y1 4000 3264 1670 2080 2500 2875 3290 4170
on request
DCS602-4803-y1 4800 3917 3000 3450 3950
DCS602-5203-y1 5200 4243 2170 2710
➀ These converters are equipped with additional components. More information on request
Table 2.2/4: Table of DCS 600 units - construction type A6 / A7
Higher currents up to 15,000 A are achieved by
paralleling converters - information on request.
