ABB DCS800 Firmware Manual

Appendix A – Macro Parameter Lists
DCS800 Firmware manual supplement for North America (rev. 2.60, 2.70) Rev. b 5/30/2008
17
Appendix A
_________________________________________________________
These tables show parameter settings for each of the 11 macros. With the exception of
“factory” macro, parameters not shown are not changed by the macro.
Factory macro changes all parameters to factory default.
Item No. Factory Standard Manual / Const Spd Hand / Auto Hand / Motor Pot Motor Pot
10.02 NotUsed NotUsed DI-3 DI-3 DI-3 DI-1
10.06 DI-2 NotUsed NotUsed NotUsed NotUsed NotUsed
10.07 NotUsed NotUsed NotUsed DI-2 NotUsed NotUsed
10.08 DI-4 NotUsed NotUsed NotUsed NotUsed NotUsed
10.15 DI-7 DI-7 DI7DI8 DI-7 DI7DI8 DI-7
10.16 DI-8 DI-8 DI7DI8 DI-1 DI7DI8 DI-8
10.17 NotUsed DI-1 DI-1 NotUsed NotUsed NotUsed
10.18 NotUsed DI-2 DI-2 NotUsed NotUsed NotUsed
10.20 DI-1 NotUsed NotUsed NotUsed NotUsed NotUsed
10.21 DI-3 NotUsed NotUsed NotUsed NotUsed NotUsed
11.02 Close Close Close DI-2 DI-4 Close
11.03 SpeedRef2301 AI-1 AI-1 AI-1 AI-1 MotorPot
11.06 SpeedRef2301 SpeedRef2301 SpeedRef2301 SpeedRef2301 MotorPot SpeedRef2301
11.12 Open Open Open Invert1102 Invert1102 Open
11.13 NotUsed NotUsed NotUsed NotUsed DI-1 DI-2
11.14 NotUsed NotUsed NotUsed NotUsed DI-2 DI-3
11.15 NotUsed NotUsed NotUsed NotUsed NotUsed DI-4
14.01 603 801 801 801 801 801
14.02 0 1 1 0 0 1
14.03 603 801 801 801 801 801
14.04 5 2 2 2 2 10
14.05 603 802 801 801 801 802
14.06 7 13 3 3 3 13
14.07 0 802 802 802 802 802
14.080 1111111111
14.09 0 801 801 801 801 801
14.10 0 10 10 10 10 8
14.16 7 7 7 7 7 7
15.01 0 104 104 104 104 104
15.06 0 113 106 106 106 113
20.18 TorqMax TorqMax TorqMax TorqMax TorqMax TorqMax
20.19 TorqMin TorqMin TorqMin TorqMin TorqMin TorqMin
23.01 0 0 0 100 0 100
23.02 0 75 75 75 0 50
23.03 0 100 100 0 0 0
24.29 Par1Sel Par1Sel DI4 Par1Sel Par1Sel Par1Sel
25.10 TorqRefA2501 TorqRefA2501 TorqRefA2501 TorqRefA2501 TorqRefA2501 TorqRefA2501
26.01 Speed Speed Speed Speed Speed Speed
26.04 TorqSel2601 TorqSel2601 TorqSel2601 TorqSel2601 TorqSel2601 TorqSel2601
26.05 NotUsed NotUsed NotUsed NotUsed NotUsed NotUsed
30.31 NotUsed DI-3 DI-3 NotUsed NotUsed NotUsed
30.32 NotUsed DI-4 DI-4 NotUsed NotUsed NotUsed
16.09 Compact Extended Extended Extended Extended Extended
Default not changed not changed not changed not changed not changed
Parameter
All others
DO5 Index
DO8 Select
Jog1
Jog2
ConvFanAck
MainContAck
Ref2Mux
Ref2Sel
MotPotDown
MotPotMin
ExtFaultSel
SpeedRef
FixedSpeed2
FixedSpeed1
TorqSel
TorqMux
TorqRefASel
TorqRefASel
ExtAlarmSel
DO5 Bit No
DO1 Index
DO1 Bit No
DO2 Index
DO2 Bit No
DO3 Index
TorqMuxMode
Index AO1
DO3 Bit No
Motor Fan Ack
OnOff1
StartStop
Direction
HandAuto
Index AO2
T
orqUsedMaxS
e
USI Sel
Off2
T
orqUsedMinSe
l
MotPotUp
Ref1Mux
Ref1Sel
DO4 Index
DO4 Bit No
