8.4.1.1 CS141 basic
For interfacing the UPS with the network without the need for additional sensors or interfaces.
Available in slot and box formats.
Supports the following protocols:
SNMP, Modbus TCP,HTTP ModBus TCP, Telnet FPT, SMTP (e-mail)
Fig 8.4.1.1-1: CS141 Basic
8.4.1.2 CS141 advanced
For interfacing UPS with the network and allowing users to connect additional sensors and I / O
options either directly to the card or with sensor manager. Available in slot and box
formats
Supports the following protocols
HTTP, ModBus TCP ,SNMP Telnet FPT, SMTP (e-mail), ModBus RS-485
Fig 8.4.1.2-1: CS141 Advanced
