The EIB Delta-Meters are a new generation of certified, electronic, electricity
meters with an integrated ABB i-bus
®
EIB communication interface.
The new EIB Delta-Meters are compact, reliable, immune to interference
impulses and suitable for use in single-phase and polyphase voltage
networks. As the meters have no mechanical moving parts, they can easily
be mounted in any position onto DIN rails according to EN 50022.The EIB
communication interface allows remote reading of the meter data via the
ABB i-bus
®
EIB for billing, energy optimisation, visualisation or installation
monitoring purposes.
They can be universally employed for submetering applications in industrial
installations, commercial buildings, offices, leisure complexes and private
households.
Special features:
● Precise measurement of energy consumption (kWh, kvarh with
combination meter)
● For 2-, 3- and 4-wire voltage networks with any load
● Integrated EIB interface for remote reading of meter data
● Network monitoring function: recording and display of up to 24 electrical
measured variables
● Automatic wiring check with an installation self-test
● Easy to read LCD display, LED indicator for energy consumption
● Direct connection up to 65 A (measuring range of 0.05 A to 65 A)
● Transformer connection (/1A or /5 A) with transformer rated meter
● Accuracy classes 1 or 2
● Tariff meter with 4 tariffs
● Fulfils standards IEC 1036/1268
● Resistant to shocks and vibration, can be mounted in any position
● System pro M design: can be snapped onto 35 mm DIN rail, sealable
1 General information
1.1 General description
EIB Delta-Meter
Electricity Meters
2
ABB i-bus
®
EIB
