52 Maintenance
13. Put the axles in the middle of the roof
support beams onto the slots near the edge
of the roof.
14. Pull and push the roof support beams into
place.
15. Install the locking pins.
16. Lock the roof support beams into position
with the locking pins.
17. Install the support beam [3] onto the two
roof support beams. Make sure that the tabs
and slots in the booms are aligned correctly.
14
13
15
16
17
