Maintenance 53
18. Install the two locking pins. Check that
everything is fastened properly by pulling
the supports from all sides.
19. Remove the eight bolts that attach the
module.
20. Loosen the eight bolts that attach the
support brackets.
21. Remove the support brackets.
22. Loosen the extraction support nut from both
extraction supports to the end of their bolts.
18
18
19
20
21
21
22
