54 Maintenance
23. Remove the rubber bolt covers of the
module extraction support.
24. Open the extraction supports.
25. Tighten the extraction support nuts.
26. Loosen the diagonal support bolts and nuts,
six total.
27. Open the diagonal supports and put their
flanges into the slots of the upright bars.
28. Tighten the diagonal support bolts.
23
23
24
24
25
26
27
27
28
