7.3.5. Unsuccessful closing operation
operation checks the correct position of the
sensors at the end of the operations (after 95ms
magnetic actuators).
If the position is incorrect (i.e. both position
open (autotrip) is performed. If this opening is not
performed correctly the status go to NOT READY
After 10 autotrip operations the Ready LED is
turned off and the unit go in NOT READY
condition. In this case it is necessary to reset the
unit (remove the auxiliary supply and discharge
the capacitors).
launched until the opening inputs remain active.
reactivate the closing signal.
and discharge of the capacitor bank.
Even after one successful operation the
unsuccessful operation counter is continuing to
increment the counter.
7.3.6. Valid signal window
A LOCAL or REMOTE opening & closing signals are
accepted on rising edge.
7.3.7. Capacitor Charge and Operating conditions
Capacitor charge and the corresponding
operating states and possible operations
Apparatus
ON OFF
Capacitor charge:
operation LED "READY" READY contact operation LED "READY" READY contact
(U > OCO
thr
)
on closed on closed
Sufficient for CO
(COthr < U < OCO
thr
)
flashing closed flashing closed
Sufficient for O
(Othr < U < CO
thr
)
flashing closed blocked off open
Not sufficient for any
(U < O
thr
)
blocked off open blocked off open
Table 18 “Ready” signal dependent on the capacitor charge
—
7. Assembly & Commissioning
The above table is valid when the UV
function is enabled.
Note: When the UV function is disabled, the
UV input is always High.
7.3.8. Auxiliary Voltage Interruption (auxiliary
voltage for the capacitor charge)
Approximately one second after a voltage
interruption, a corresponding signal occurs over
diagram).
It is then possible to open the apparatus, by
means of remote signals or by using local push
1.5 - 2 minutes.
After expiry of this time period, the apparatus can
manual tripping crank.
7.3.9. Manual Operation
is to be used. It is not suitable for storing
The apparatus can only be switched off
manually, but not switched on
