SV GOOSE
TimeSync
(SNTP)
MMS Protocol Suite
GSSE
TCP/IP
T-Profile
ISO CO
T-Profile
ISO/IEC 8802-2 LLC
GSSE
T-Profile
UDP/IP
ISO/IEC 8802-3 Ethertype
Sampled
Values
(Multicast)
Generic
Object
Oriented
Substation
Event
Time
Sync
Core
ACSI
Services
Generic
Substation
Status
Event
ISO/IEC 8802-3
IEC09000153-1-en.vsd
IEC09000153 V1 EN-US
Figure 7: Overview of functionality and profiles according to IEC 61850-8-1
Out of this content, the implementation supports:
• Sampled values according to 9-2LE
• GOOSE
• TimeSync using SNTP
• The peer-to-peer/vertical communication using MMS protocol suite with the
T-profile TCP/IP
For each of the above, the resulting underlying protocols as stated in Figure 7.
See the PICS and PIXIT for more information.
Section 4 1MRK 511 393-UEN A
Communication profile
32 670 series 2.2 IEC
Communication protocol manual
