GILLETTE ŁÓDŹ
Robotic station for packing FFS1 dispensers
Figure 54 Frame transport handles
Transport of feeders
The conveyors should be moved using a forklift. The forklift should be placed halfway
along the feeder as shown in the figure below. Feeder weight ~600kg.
