10 User Guide
The coupler
—
Figure 3 Typical ¾ NPT LWT310 instrument coupler
Probe attachment
thread
¾ NPT thread Head coupler
thread
Head sensor
socket
Alignment
bumpers
As shipped
—
Figure 4 Head-coupler assembly
