44 User Guide
—
Figure 33 Accessing the write-protection screw
Nameplate
Write-protection screw
2 Using a suitable screwdriver, fully press down on the write-protection screw and turn 90° clockwise
to activate hardware write protection or, if already activated, 90° counterclockwise to deactivate it.
—
Figure 34 Activating hardware write protection
Deactivated write
protection (default)
Activated write
protection
3 Put the nameplate back in place.
