8
2.2.5 General
Only the specified cables and adaptors may be
fitted, and in the manner described elsewhere in
this manual.
Some of these options may not be suitable for a
particular installation. For example, if
mechanical damage to cable could occur, only
armoured cable or conduit would be used. Local
and National requirements may also preclude
some of the above methods.
2.2.6 MagMaster Sensor Temperature Limits
Table 2.1 Temperature Limits
Std. Standard temperature versions – Maximum process and ambient temperatures in °C.
Ext. High temperature versions which are fitted with a terminal box extension – Maximum process
temperatures in °C; ambient temperature limits remain at 60°C.
Note.
Actual process temperature limit may be restricted further by the temperature limit of the lining option
chosen.
noitpircseDrosneSretsaMgaM epyTdtStxE
mm051otmm51epytegnalF 3AH06021
mm006otmm002epytegnalF 5AH06001
...2 FM APPROVED/CSA CERTIFIED FLOWMETERS
